Overview

TCC models are storage tanks for large quantities of water or chemical products requesting the possibility of total empty, useful for those applications where is necessary frequent cleanings or replaces to restart the process, removing insoluble’s or frequent disinfections.

Built from HDPE sheets by welding and extrusion procedures are compatible with most part of commercial chemical products and for that an additional value on conception and erection of water treatment plants and management of large quantities of chemical.

The cylindrical roof conception permit manufacture large diameters tanks with correspondent high content volumes  depending the product characteristics and physical operation conditions.

Design by our technical experts assisted by dedicated software all tanks are calculated with one single vertical section, safety factors and manufacturing procedures following the German norm DVS2005 conferring high robust walls, in opposite, the suspended conical bottom that limit the application till 10 m3 volumes.

All TCC units are “tailor made” manufacture and for that all data showed in the tables is just an indication follow the best compromise cost per m3 attempt to maximum efficiency for raw materials, otherwise is possible study others volumes, dimensions and configurations. Top man hole, hydraulic connections (position and dimensions), optional level and other accessories as costumer convenience.

  • Range of tanks normally build in HDPE but available in other materials as process requests or costumer exigencies.
  • Free selectable diameter/high configuration available with our engineering department to cover the most exigent specifications.
  • Large type of lids, connections, bunds, levels and other possible accessories are available and can be installed as project specifications.
